产品橱窗/二极管系列(40W - 500W)

ESD / TVS Arrays Page 4 (450W~500W)
Part Number	Peak Power Dissipation (W) tp=8*20us	Reverse Stand-off Voltage	Max Clamping Voltage	Peak Pelse Current	Off-State Capacitance	Package	Circuit Figure
		Vrwm(V)	Vc(Max)	Vc@A	1M Hz Zero DC
		Vrwm(V)	Vc(Max)	Vc@A	Co pF
YSLC2504N	450 W	2.5	4.5	1.0	4.0	TSON10	34
YSLC3304N	450 W	3.3	5.5	1.0	4.0	TSON10	34
YSESD3Z3.3T1G	500 W	3.3	6.5	1.0	500.0	SOD-323	21
YSESD3Z5.0T1G	500 W	5.0	9.8	1.0	350.0	SOD-323	21
YSESD3Z12T1G	500 W	12.0	19.0	1.0	150.0	SOD-323	21
YSESD3Z15T1G	500 W	15.0	24.0	1.0	100.0	SOD-323	21
YSESD3Z24T1G	500 W	24.0	43.0	1.0	90.0	SOD-323	21
YSESD3Z36T1G	500 W	36.0	60.0	1.0	75.0	SOD-323	21
YSESD3Z3.3BT1G	500 W	3.3	7.5	1.0	450.0	SOD-323	48
YSESD3Z05BT1G	500 W	5.0	9.8	1.0	200.0	SOD-323	48
YSESD3Z12BT1G	500 W	12.0	19.0	1.0	100.0	SOD-323	48
YSESD3Z15BT1G	500 W	15.0	24.0	1.0	75.0	SOD-323	48
YSESD3Z24BT1G	500 W	24.0	40.0	1.0	50.0	SOD-323	48
YSSR05	500 W	5.0	9.8	1.0	1.0	SOT-143	30
YSE3302D	500 W	3.3	5.1	1.0	3.5.0	SOT-23	23
YSMDA03C YSMDA03C	500 W	3.3	9.0	5.0	450.0	SO-08	35
YSMDA05C YSMDA05C	500 W	5.0	10.0	5.0	300.0	SO-08	35
YSMDA12C YSMDA12C	500 W	12.0	22.0	5.0	185.0	SO-08	35
YSMDA15C YSMDA15C	500 W	15.0	27.0	5.0	140.0	SO-08	35
YSMDA24C YSMDA24C	500 W	24.0	45.0	5.0	88.0	SO-08	35
YSMDA36C YSMDA36C	500 W	36.0	65.0	5.0	45.0	SO-08	35
YSRDA3.3-4 YSRDA3.3-4	500 W	3.3	6.5	1.0	15.0	SOIC-8	29
YSRDA05-4 YSRDA05-4	500 W	5.0	9.8	1.0	15.0	SOIC-8	29
YSRDA12-4 YSRDA12-4	500 W	12.0	19.0	1.0	15.0	SOIC-8	29
